Hospitality
Unforgettable experiences begin with how a space makes you feel. PassivGlas™ vacuum glazing helps craft that atmosphere – keeping interiors warm, quiet, and inviting.
Energy Efficiency and Comfort through Thermal Control
With an impressively low U-value of 0.49 W/m²K, PassivGlas™ vacuum glazing dramatically reduces unwanted heat gain and loss. Helping to create energy-efficient hospitality spaces. This thermal insulation performance minimises the need for energy-intensive heating or cooling systems, helping hospitality venues cut down on operational costs while promoting sustainability. More importantly, it creates a consistently comfortable indoor climate, allowing patrons to enjoy their meals or social interactions in a space that feels just right – neither too hot nor too cold.
Architectural Elegance Meets Functional Design
Sustainable Glazing for Commercial Buildings
PassivGlas™ isn’t just about performance – it’s about enhancing visual appeal. The glazing’s optical clarity and sleek profile contribute to a contemporary architectural aesthetic. Whether it’s a restaurant with panoramic views or a boutique café in an urban setting, PassivGlas™ integrates seamlessly into modern design schemes. The result is an elegant and refined façade that communicates quality and attention to detail from the first glance.
Exceptional Thermal Insulation
Achieve U-values as low as 0.49 W/m²K to reduce heat loss and enhance year-round comfort.
Superior Acoustic Performance
A vacuum layer minimises sound transmission for a quieter indoor space. UKAS tested sound reduction of Rw 36 dB
Slim, Lightweight Design
With a thickness of just 6.15 mm, ideal for retrofits or new builds.
Guaranteed for 15 Years
Built for sustainability and reducing carbon footprints. Backed with a 15 year guarantee
Acoustic Insulation for a Serene Environment
Noise can break an atmosphere, especially in bustling city centres or high-traffic areas. PassivGlas™ offers exceptional acoustic insulation (Rw: 36 dB), significantly reducing external sounds and creating a peaceful sanctuary inside. This level of sound control allows guests to converse easily, focus on their experience, and feel immersed in the space – a crucial element for memorable dining or social gatherings.
Multi-Sensory Experience for Memorable Hospitality
Great experiences are rooted in the senses. PassivGlas™ supports this by modulating temperature, enhancing visual clarity, and dampening noise – elements that combine to create a welcoming, multi-sensory environment. Whether patrons are enjoying a quiet coffee, a lively dinner, or a business lunch, the ambience contributes to their overall impression. By setting the right tone, the glazing plays a subtle yet powerful role in building loyalty and emotional connection with your guests.
Natural Light and Sustainability in Hospitality Spaces
In the hospitality industry, atmosphere is everything and natural light is key. PassivGlas™ offers up to 80% light transmittance, allowing generous amounts of daylight to flood interior spaces. This not only elevates mood and enhances the visual appeal of the environment but also reduces reliance on artificial lighting. Paired with thermal and acoustic benefits, this creates a sustainable, cost-effective solution for restaurants, bars, and cafés. It also underscores a venue’s commitment to Corporate Social Responsibility, showcasing investment in both guest wellbeing and environmental stewardship.
Frequently Asked Questions
What are vacuum units?
Vacuum Insulated Glazing or VIG is an advanced fenestration type of insulating unit. It consists of two glass panes, like a standard Insulating unit, but rather than the spacer bar and an air gap, VIG’s are separated by a micro vacuum gap, with a glass solder edge seal.
Are they fully tested?
Yes, they are tested to recognised industry standards:
Impact resistance: EN 12150-2 & ANSI Z97.1-37 & EN 12600 & BS356 (recently completed)
Weathering: EN1279-5 & ASTM E546/E2188/E2189
U-Value: ISO8301/EN12667 (Recently UKAS tested) & ASTM C518
Soundproof: ISO 10140-2 (Recently UKAS tested)
Do the standard units use coated glass?
Yes, all PassivGlas™ Linear units incorporate a Low-e single silver toughenable coating.
In order to meet the current Part O regulations, a Low-e double silver coating would be needed to meet the 70/40 requirements. Please check with VGN as to availability and MOQ for this product range.
What is the expected life?
Expected life on the unit is 25+ years due to there being no spacer bar to fail.
Will there be any condensation
Condensation is formed when the air temperature surrounding an object falls below the dew point and changes into a liquid
Internal:
Although condensation will not form on the internal surface of a VIG unit, Vacuum Glazing does not eradicate condensation from the room.
The warmer inner glass will potentially change the rooms cold point.
It is advisable to ensure all rooms have effective ventilation/circulation.
External:
Condensation may form on the external glass surface under certain conditions.
Generally, forms a grid around the micro-pillars.
Will disappear when the outside temperature warms with the morning sun.
It is an indication of how efficiently your windows are at reducing thermal loss.
Condensation between glasses:
An indication that the Vacuum has been lost.
Consult your supplier to confirm course of action.
